Product Summary

The SY8031 is a low power limiting post amplifier designed for use in fiber-optic optical modules for multirate applications up to 1.25Gbps. The device connects to a typical transimpedance amplifier (TIA) and can produce output signals to CML-level waveforms. Intended for the GbE and Fibre Channel applications, the SY8031 offers a wide LOS range. It is able to detect input signals for as low as 5mVpp and as high as 100mVpp. The applications of the SY8031 include Gigabit Ethernet, Fibre Channel, GEPON.

Parametrics

SY8031 absolute maximum ratings: (1)Supply Voltage (VCC): 0V to +4.0V; (2)Input Voltage (DIN, /DIN): 0 to VCC; (3)Output Current (IOUT): ±25mA; (4)EN Voltage: 0 to VCC; (5)VREF Current: -800μA to +500μA; (6)LOSLVL Voltage: VREF to VCC; (7)Lead Temperature (soldering, 20sec.): 260℃; (8)Storage Temperature (Ts): -65℃ to +150℃.

Features

SY8031 features: (1)Ultra wide LOS Range (5mVpp to 100mVpp); (2)Single 2.5V power supply; (3)Ultra low power consumption (55mW typ); (4)125Mbps to 1.25 Gbps operation; (5)Low-noise CML data outputs; (6)TTL /EN input; (7)Programmable LOS level (LOSLVL); (8)Internal 50Ohm termination; (9)Available in a tiny 3mm x 3mm QFN package.

Diagrams

SY8031 block diagram
