Product Summary

The STM32F101C8T6 is a medium-density access line MCU which incorporates the high-performance 32-bit RISC core operating at a 36 MHz frequency, high-speed embedded memories (Flash memory up to 128 Kbytes and SRAM up to 16 Kbytes), and an extensive range of enhanced peripherals and I/Os connected to two APB buses. All devices offer standard communication interfaces (two I2Cs, two SPIs, and up to three USARTs), one 12-bit ADC and three general-purpose 16-bit timers. These features make the STM32F101xx medium-density access line microcontroller family suitable for a wide range of applications: Application control and user interface, Medical and handheld equipment, PC peripherals, gaming and GPS platforms, Industrial applications: PLC, inverters, printers, and scanners, Alarm systems, Video intercom and HVAC.

Parametrics

STM32F101C8T6 absolute maximum ratings: (1)External main supply voltage: -0.3 to 4.0V; (2)Input voltage on five volt tolerant pin: VSS-0.3 to +5.5V; (3)Input voltage on any other pin: VSS-0.3 to VDD+0.3V; (4)Variations between different VDD power pins: 50mV; (5)Variations between all the different ground pins: 50mV.

Features

STM32F101C8T6 features: (1)Single-cycle multiplication and hardware division; (2)64 to 128 Kbytes of Flash memory; (3)10 to 16 Kbytes of SRAM; (4)Clock, reset and supply management; (5)Serial wire debug (SWD) and JTAG interfaces; (6)Low power; (7)Conversion range: 0 to 3.6 V; (8)Temperature sensor; (9)Up to 3 USARTs (ISO 7816 interface, LIN, IrDA capability, modem control); (10)Up to 2 SPIs (18 Mbit/s); (11)CRC calculation unit, 96-bit unique ID.

Diagrams

STM32F101C8T6 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
STM32F101C8T6
STM32F101C8T6
STMicroelectronics
ARM Microcontrollers (MCU) 32BIT Cortex M3 64KB 10KB RAM 1X12 ADC
Data Sheet
0-1: $2.78
1-10: $2.50
10-100: $2.03
100-250: $1.84
STM32F101C8T6TR
STM32F101C8T6TR
STMicroelectronics
ARM Microcontrollers (MCU) 32BIT Cortex M3 M/D Access Line
Data Sheet
0-1795: $1.49
1795-2000: $1.44
2000-2400: $1.44
2400-5000: $1.39
