Product Summary

The SP7656EN2-L is a PWM controlled step down (buck) voltage mode regulator co-packaged with a P-Channel FET. The SP7656EN2-L operates from 4.5V to 29V making it suitable for 5V, 12V and 24V applications. The programmable overcurrent protection is based on internal FET resistance sensing and allows setting the overcurrent protection value up to a 300mV threshold (measured between VIN-LX). The SP7656EN2-L is packaged in a thermally enhanced 8-pin SO8 package making it one of the smallest converters available capable of operating from 5, 9, 12, 18 and 24VDC supplies.

Parametrics

SP7656EN2-L absolute maximum ratings: (1)PVIN: -0.3V to 30V SVIN: -0.3V to 30V; (2)Lx: -2V to 30V; (3)ISET: -2V to 30V; (4)FB: -0.3V to 5.5V; (5)Storage Temperature: -65 °C to 150 °C; (6)Junction Temperature: -40°C to 125°C; (7)Lead Temperature (Soldering, 10 sec): 300 °C.

Features

SP7656EN2-L features: (1)Wide Input Voltage Range 4.5V – 29V; (2)3 Amps Continuous 4 Amps Peak Output Current; (3)Internal Compensation; (4)Input Feedforward Control improves Transient and Regulation; (5)600kHz Constant Frequency Operation; (6)Low 0.6V Reference Voltage; (7)High output setpoint accuracy of 1%; (8)Internal Soft Start; (9)Small SO8-EP Thermally Enhanced Package; (10)Adjustable Overcurrent Protection; (11)Lead Free, RoHS Compliant Package.
