Product Summary

The SP706TCU-L/TR is a microprocessor (μP) supervisory circuit that integrate myriad components involved in discrete solutions which monitor power-supply and battery, in μP, and digital systems. The SP706TCU-L/TR will significantly improve system reliability and operational efficiency when compared to results obtained with discrete components. The features of the SP706TCU-L/TR include a watchdog timer, a μP reset, a Power Fail Comparator, and a manual-reset input. The SP706TCU-L/TR is ideal for +3.0V or +3.3V applications in automotive systems, computers, controllers, and intelligent instruments. The SP706TCU-L/TR is an ideal solution for systems in which critical monitoring of the power supply to the μP and related digital components is demanded.

Parametrics

SP706TCU-L/TR absolute maximum ratings: (1)VCC: -0.3V to +6.0V; (2)All Other Inputs (Note 1): -0.3V to (VCC +3.0V); (3)Input Current:; (4)VCC: 20mA; (5)GND: 20mA; (6)Output Current (all outputs): 20mA; (7)ESD Rating: 2kV; (8)Continuous Power Dissipation Plastic DIP (derate 9.09mW/OC above +70OC): 727mW; (9)SO, (derate 5.88mW/OC above +70OC): 471mW, Mini SO, (derate 4.10mW/OC above +70OC): 330mW; (10)Storage Temperature Range: -65°C to +160°C; (11)Lead Temperature (solding 10 sec): +300°C.

Features

SP706TCU-L/TR features: (1)RESET Pulse Width - 200ms; (2)Independent Watchdog Timer - 1.6 sec Timeout (SP706P/S/R/T); (3)40μA Maximum Supply Current; (4)Debounced TTL/CMOS Manual-Reset Input; (5)RESET Asserted Down to VCC = 1V; (6)WDI Can Be Left Floating, Disabling the Watchdog Function; (7)Built-In Vcc Glitch Immunity; (8)Available in 8-pin PDIP, NSOIC, and μSOIC packages; (9)Voltage Monitor for Power Failure or Low Battery Warning; (10)Pin Compatible Enhancement to Industry Standards 706P/R/S/T and 708R/S/T.
