SP6661EU

Voltage Converter, CMOS, +5.6V, 200mA, MSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: SP6661EU

Brand:: Sipex Corporation - Exar | Pack: MSOP | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:SP6661EU
US $0.30 - 0.50
Quantity:

piece

Product Summary

The SP6661EU is a CMOS DC-DC Monolithic Voltage Converter that can be implemented as a Voltage Inverter or a Positive Voltage Doubler. As a Voltage Inverter, a -1.5V to -5.0V output can be converted from a +1.5V to +5.0V input. As a Voltage Doubler, a +5.0V to +10.0V output can be provided from a +2.5V to +5.0V input. The SP6661EU is ideal for both battery-powered and board level voltage conversion applications with a typical operating current of 3mA and a high efficiency (>90%) over most of its load-current range. Typical end products for this device are disk drive supplies, operational amplifier and interface power supplies, medical instruments, and hand held and laptop computers.

Parametrics

SP6661EU absolute maximum ratings: (1)Power Supply Voltage (V+ to GND or GND to OUT): +5.6V; (2)LV Input Voltages: (OUT - 0.3V) to (V+ + 0.3V); (3)OUT and V+ Continuous Output Current: 200mA; (4)Operating Temperature: -40℃ to +85℃; (5)Storage Temperature:-65℃ to +150℃; (6)Lead Temperature (soldering 10s): +300℃.

Features

SP6661EU features: (1)Inverts or Doubles Input Supply Voltage; (2)92% Power Efficiency at 100mA; (3)120kHz/900kHz Selectable Oscillator Frequency; (4)4.5Ω Output Resistance Using 3.3μF Ceramic Caps; (5)Low Voltage Battery Operation; (6)Ideal for 3.6V Lithium Ion Battery or 5.0V Input; (7)High Output Current-200mA; (8)Low Profile Solution; (9)1.5V Inverter Startup Guaranteed; (10)Pin-Compatible High-Current Upgrade of the ICL7660 and 660 Industry Standard.
