SP3232ECY-L/TR

RS-232 Transceiver, 0.1μF, +3.3V, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: SP3232ECY-L/TR

Brand:: Exar Corporation - EXAR | Pack: TSSOP | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:SP3232ECY-L/TR
US $0.30 - 0.50
Quantity:

piece

Product Summary

The SP3232ECY-L/TR is an RS-232 transceiver solution intended for portable or handheld applications such as notebook or palmtop computers. The SP3232ECY-L/TR has a high-efficiency, charge-pump power supply that requires only 0.1μF capacitors in 3.3V operation. This charge pump allows the SP3232ECY-L/TR to deliver true RS-232 performance from a single power supply ranging from +3.3V to +5.0V. This series is ideal for portable or hand-held applications such as notebook or palmtop computers.

Parametrics

SP3232ECY-L/TR absolute maximum ratings: (1)VCC: -0.3V to +6.0V; (2)V+ (NOTE 1): -0.3V to +7.0V; (3)V- (NOTE 1): +0.3V to -7.0V; (4)V+ + |V-| (NOTE 1): +13V; (5)ICC(DC VCC or GND current): ±100mA; (6)Storage Temperature: -65℃ to +150℃.

Features

SP3232ECY-L/TR features: (1)Meets true EIA/TIA-232-F Standards from a +3.0V to +5.5V power supply; (2)Minimum 120Kbps Data Rate Under Full Load; (3)Interoperable with RS-232 down to +2.7V power source; (4)Enhanced ESD Specifications.
