SN75LVDS83BDGGR

transmitter, 1.8 to 3.3V, 170mW, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.06~0.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.10 / Piece
1000 ~ 10000 :	0.08 / Piece
10000 ~ 100000 :	0.06 / Piece

PartNumber:: SN75LVDS83BDGGR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 13+

Availability:: Supply Ability: 1000000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-08

From Other Seller

Part Number:SN75LVDS83BDGGR
US $0.06 - 0.10
SN75LVDS83BDGGR

US $0.09 - 5.99 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN75LVDS83BDGGR is a Flatlink transimitter. The SN75LVDS83BDGGR contains four 7-bit parallel-load serial-out shift registers, a 7X clock synthesizer, and five Low-Voltage Differential Signaling (LVDS) line drivers in a single integrated circuit. Applications of the SN75LVDS83BDGGR include: LCD Display Panel Driver, UMPC and Netbook PC and Digital Picture Frame.

Parametrics

SN75LVDS83BDGGR absolute maximum ratings: (1) Supply voltage range, VCC, IOVCC, LVDSVCC, PLLVCC: -0.5 to 4V; (2) Voltage range at any output terminal: -0.5 to Vcc +0.5V; (3) Voltage range at any input terminal: -0.5 to IOVCC + 0.5V; (4) Human Body Model (HBM) all pins ESD rating: 5kV; (5) Charged Device Model (CDM) all pins ESD rating: 500V; (6) machine Model (MM) all pins: 150V.

Features

SN75LVDS83BDGGR features: (1) LVDS Display Serdes Interfaces Directly to LCD Display Panels with Integrated LVDS; (2) Package Options: 4.5mm x 7mm BGA, and 8.1mm x 14mm TSSOP; (3) 1.8V up to 3.3V Tolerant Data Inputs to Connect Directly to Low-Power, Low-Voltage Application and Graphic Processors; (4) Transfer Rate up to 135Mpps (Mega Pixel Per Second); Pixel Clock Frequency Range 10MHz to 135MHz; (5) Suited for Display Resolutions Ranging From HVGA up to HD With Low EMI; (6) Operates From a Single 3.3V Supply and 170mW (typ.) at 75MHz; (7) 28 Data Channels Plus Clock In Low-Voltage TTL to 4 Data Channels Plus Clock Out Low-Voltage Differential; (8) Support Spread Spectrum Clocking (SSC) .
