SN74LVTH245APW

SN74LVTH245APW, 3.3-V ABT 16-bit Edge-Triggered D-type flip-flop, 30mA, 50mA, -0.5V to 7V, TSSOP48

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: SN74LVTH245APW

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-17

From Other Seller

Part Number:SN74LVTH245APW
US $0.30 - 0.50
Quantity:

piece

Product Summary

The SN74LVTH245APW is a 3.3-V ABT 16-bit Edge-Triggered D-type flip-flop with 3-state outputs. The SN74LVTH245APW is particularly suitable for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers. The SN74LVTH245APW can be used as two 8-bit flip-flops or one 16-bit flip-flop. On the positive transition of the clock (CLK), the Q outputs of the flip-flop take on the logic levels set up at the D inputs.

Parametrics

SN74LVTH245APW absolute maximum ratings: (1)Supply voltage range: -0.5V to 4.6V; (2)Input voltage range: -0.5V to 7 V; (3)Voltage range applied to any output in the high-impedance or power-off state: -0.5V to 7V; (4)Voltage range applied to any output in the high state: -0.5V to VCC+0.5V; (5)Current into any output in the low state: 30mA; (6)Current into any output in the high state: 30mA; (7)Input clamp current VI＜0 :–50mA; (8)Output clamp current VO＜0 :–50mA; (9)θJA Package thermal impedance: 70℃/W; (10)Storage temperature range: –65℃ to 150℃.
