Product Summary

The SII8338BOC is an Advanced Video Processor. The SII8338BOC is a fully integrated system solution for digital televisions and integrated HDTVs that sets new price performance standards for the digital TV market. The SII8338BOC integrates a complete front-end processor that handles a combination of up to 12 composite, S-video, and component video signals. The SII8338BOC inputs support worldwide NTSC, PAL, and SECAM television standards making a single worldwide TV platform possible. The applications of the SII8338BOC include LCD Televisions, Plasma Televisions, Integrated DTVs, Multi-function Monitors, Projection Televisions.

Features

SII8338BOC features: (1)12-input TV Front-end Processor; (2)Video Decoder with 3D Comb Filter; (3)Dual Video Processing Paths for PIP; (4)PIP/POP Processor; (5)High-Quality Scaling; (6)Motion Adaptive Video Deinterlacing; (7)ITU-R BT.656 Input; (8)Frame Rate Conversion; (9)Advanced Image Processing; (10)Integrated 166MHz 32-bit MIPS RISC Microprocessor; (11)24-bit OSD Processor; (12)DAC/TTL/LVDS Output.

Diagrams

SII8338BOC block diagram
