Product Summary
The SI4330-B1-FMR is a dual n-channel 30-V (D-S) MOSFET.
Parametrics
SI4330-B1-FMR absolute maximum ratings: (1)Drain-Source Voltage VDS: 30 V; (2)Gate-Source Voltage VGS: 20V; (3)Pulsed Drain Current IDM: 30A; (4)Continuous Source Current (Diode Conduction)a IS: 1.7A; (5)Maximum Power Dissipationa TA = 25°C PD: 2.0 W; (6)Operating Junction and Storage Temperature Range TJ, Tstg: −55 to 150°C.
Features
SI4330-B1-FMR features: (1)TrenchFET Power MOSFET; (2)100% Rg Tested.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() SI4330-B1-FMR |
![]() Silicon Labs |
![]() RF Receiver Si4330 EZradioPRO Transceiver (rev B1) |
![]() Data Sheet |
![]()
|
|
||||||
