S29GL064N90TFI040

S29GL064N90TFI040, single-power Flash memory, –0.5 V to +4.0 V, 200 mA, TSOP, SPANSION

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.50 / Piece
101 ~ 1000 :	1.40 / Piece
1001 ~ 10000 :	1.20 / Piece

PartNumber:: S29GL064N90TFI040

Brand:: SPANSION - spansion | Pack: TSOP | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-10-24

From Other Seller

Part Number:S29GL064N90TFI040
US $1.20 - 1.50
S29GL064N90TFI040

US $1.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The S29GL064N90TFI040 is a 3.0-Volt single-power Flash memory. The S29GL064N90TFI040 is manufactured using 110 nm MirrorBit technology. The S29GL064N90TFI040 is a 64-Mb device organized as 4,194,304 words or 8,388,608 bytes. The S29GL064N90TFI040 is a 32-Mb device organized as 2,097,152 words or 4,194,304 bytes. Depending on the model number, the S29GL064N90TFI040 has 16-bit wide data bus only, or a 16-bit wide data bus that can also function as an 8-bit wide data bus by using the BYTE# input. The S29GL064N90TFI040 can be programmed either in the host system or in standard EPROM programmers.

Parametrics

S29GL064N90TFI040 absolute maximum ratings: (1)Storage Temperature Plastic Packages: –65 to +150 ℃; (2)Ambient Temperature with Power Applied: –65 to +125 ℃; (3)Voltage with Respect to Ground: –0.5 V to +4.0 V; (4)Output Short Circuit Current (Note 3): 200 mA.

Features

features: (1)Advanced Sector Protection: offers Persistent Sector Protection and Password Sector Protection; (2)Program Suspend & Resume: read other sectors before programming operation is completed; (3)Erase Suspend & Resume: read/program other sectors before an ; (4)erase operation is completed; (5)Data# polling & toggle bits provide status; (6)CFI (Common Flash Interface) compliant: allows host system to ; (7)identify and accommodate multiple flash devices; (8)Unlock Bypass Program command reduces overall multiple-word ; (9)programming time; (10)WP#/ACC input accelerates programming time for greater throughput during system production. Protects first or last sector regardless of sector protection settings on uniform sector models; (11)Hardware reset input (RESET#) resets device; (12)Ready/Busy# output (RY/BY#) detects program or erase cycle; (13)completion.
