REF3033AIDBZR

REF3033AIDBZR, low voltage dropout voltage reference, SOT, 7.0V, 25mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: REF3033AIDBZR

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-26

From Other Seller

Part Number:REF3033AIDBZR
US $1.00 - 3.00
Quantity:

piece

Product Summary

The REF3033AIDBZR is a precision, low power, low voltage dropout voltage reference family available in a tiny SOT23-3. The REF3033AIDBZR small size and low power consumption (50μA max) make it ideal for portable and battery-powered applications. The REF30xx does not require a load capacitor, but is stable with any capacitive load. The applications of the REF3033AIDBZR include portable, battery-powered equipment, data acquisition systems, medical equipment, hand-held test equipment.

Parametrics

REF3033AIDBZR absolute maximum ratings: (1)Supply Voltage, V+ to V–: 7.0V; (2)Output Short-Circuit: Continuous; (3)Operating Temperature: -40℃ to +125℃; (4)Storage Temperature: -65℃ to +150℃; (5)Junction Temperature: +150℃; (6)Lead Temperature (soldering, 10s): +300℃.

Features

REF3033AIDBZR features: (1)MicroSize package: SOT23-3; (2)Low dropout: 1mV; (3)High output current: 25mA; (4)High accuracy: 0.2%; (5)Low IQ: 50μA max; (6)Excellent specified drift performance: 50ppm/℃ (max) from 0℃ to +70℃; 75ppm/℃ (max) from -40℃ to +125℃.
