REF192GSZ-REEL7

REF192GSZ-REEL7, precision band gap voltage reference, 18 V, 45 μA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: REF192GSZ-REEL7

Brand:: Analog Devices Inc - ADI | Pack: SOP | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-01

From Other Seller

Part Number:REF192GSZ-REEL7
US $1.00 - 3.00
Quantity:

piece

Product Summary

The REF192GSZ-REEL7 is a precision band gap voltage reference uses a patented temperature drift curvature correction circuit and laser trimming of highly stable, thin-film resistors to achieve a very low temperature coefficient and high initial accuracy. The REF192GSZ-REEL7 is made up of micropower, low dropout voltage (LDV) devices, providing stable output voltage from supplies as low as 100 mV above the output voltage and consuming less than 45 μA of supply current. The applications of the REF192GSZ-REEL7 include Portable instruments, ADCs and DACs, Smart sensors, Solar-powered applications, Loop current-powered instruments.

Parametrics

REF192GSZ-REEL7 absolute maximum ratings: (1)Supply Voltage: -0.3 V to +18 V; (2)Output to GND: -0.3 V to VS + 0.3 V; (3)Output to GND Short-Circuit Duration: Indefinite; (4)Storage Temperature Range, PDIP, SOIC_N Package: -65℃ to +150℃; (5)Operating Temperature Range REF19x: -40℃ to +85℃; (6)Junction Temperature Range, PDIP, SOIC_N Package: -65℃ to +150℃; (7)Lead Temperature Range (Soldering 60 sec): 300℃.

Features

REF192GSZ-REEL7 features: (1)Initial accuracy: ±2 mV maximum; (2)Temperature coefficient: 5 ppm/℃ maximum; (3)Low supply current: 45 μA maximum; (4)Sleep mode: 15 μA maximum; (5)Low dropout voltage; (6)Load regulation: 4 ppm/mA; (7)Line regulation: 4 ppm/V; (8)High output current: 30 mA; (9)Short-circuit protection.
