PIC16F818T-I/SO

18-Pin Enhanced Flash Microcontroller, SOIC18, -0.3 to +7.5V, Low-Voltage Programming

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.00~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	6.00 / Piece
101 ~ 1000 :	5.00 / Piece
1001 ~ 10000 :	4.00 / Piece

PartNumber:: PIC16F818T-I/SO

Brand:: Microchip Technology - Microchip | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-31

From Other Seller

Part Number:PIC16F818T-I/SO
US $4.00 - 6.00
Quantity:

piece

Product Summary

The PIC16F818T-I/SO is an 18-Pin Enhanced Flash Microcontroller with nanoWatt Technology. It belongs to the Mid-Range family of the PICmicro devices. The PIC16F818T-I/SO differs from each other in the amount of Flash program memory, data memory and data EEPROM.

Parametrics

PIC16F818T-I/SO absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on any pin with respect to VSS (except VDD and MCLR): -0.3V to (VDD + 0.3V); (4)Voltage on VDD with respect to VSS: -0.3 to +7.5V; (5)Voltage on MCLR with respect to VSS: -0.3 to +14V; (6)Total power dissipation: 1W; (7)Maximum current out of VSS pin: 200 mA; (8)Maximum current into VDD pin: 200 mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ±20 mA; (10)Output clamp current, IOK (VO < 0 or VO > VDD): ±20 mA; (11)Maximum output current sunk by any I/O pin: 25 mA; (12)Maximum output current sourced by any I/O pin: 25 mA; (13)Maximum current sunk by PORTA: 100 mA; (14)Maximum current sourced by PORTA: 100 mA; (15)Maximum current sunk by PORTB: 100 mA; (16)Maximum current sourced by PORTB: 100 mA.

Features

PIC16F818T-I/SO features: (1)100,000 erase/write cycles Enhanced Flash program memory typical; (2)1,000,000 typical erase/write cycles EEPROM data memory typical; (3)EEPROM Data Retention: > 40 years; (4)In-Circuit Serial Programming (ICSP) via two pins; (5)Processor read/write access to program memory; (6)Low-Voltage Programming; (7)In-Circuit Debugging via two pins.
