PIC16F628-04/P

8-bit microcontroller, fully-static, 25 mA, 800 mW, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: PIC16F628-04/P

Brand:: Microchip Technology - Microchip | Pack: DIP | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-17

From Other Seller

Part Number:PIC16F628-04/P
US $0.30 - 0.50
Quantity:

piece

Product Summary

The PIC16F628-04/P is an 18-Pin FLASH-based low-cost, high-performance, CMOS, fully-static, 8-bit microcontroller. A variety of frequency ranges and packaging options are available. The PIC16F628-04/P is supported by a full-featured macro assembler, a software simulator, an in-circuit emulator, a low-cost development programmer and a full-featured programmer.

Parametrics

PIC16F628-04/P absolute maximum raings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: -0.3 to +v; (4)Voltage on MCLR and RA4 with respect to VSS: -0.3 to +14V; (5)Voltage on all other pins with respect to VSS: -0.3V to VDD + 0.3V; (6)Total power dissipation: 800 mW; (7)Maximum current out of VSS pin: 300 mA; (8)Maximum current into VDD pin: 250 mA; (9)Input clamp current: ± 20 mA; (10)Output clamp current: ± 20 mA; (11)Maximum output current sunk by any I/O pin: 25 mA; (12)Maximum output current sourced by any I/O pin: 25 mA; (13)Maximum current sunk by PORTA and PORTB: 200 mA; (14)Maximum current sourced by PORTA and PORTB: 200 mA.

Features

PIC16F628-04/P features: (1)Programmable weak pull-ups on PORTB; (2)Programmable code protection; (3)Low voltage programming; (4)Power saving SLEEP mode; (5)Selectable oscillator option; (6)CMOS Technology; (7)15 I/O pins with individual direction control; (8)High current sink/source for direct LED drive; (9)Interrupt capability; (10)16 special function hardware registers; (11)8-level deep hardware stack; (12)Direct, Indirect and Relative addressing modes.
