PIC16F505-I/SL

8-Bit Flash Microcontroller, 8/14-Pin, ±20 mA, +6.5V, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: PIC16F505-I/SL

Brand:: Microchip Technology - Microchip | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-17

From Other Seller

Part Number:PIC16F505-I/SL
US $0.30 - 0.50
PIC16F505-I/SL IC MCU 8BIT

US $0.10 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PIC16F505-I/SL is an 8/14-Pin, 8-Bit Flash Microcontroller.A variety of packaging options are available. Depending on application and production requirements, the proper device option can be selected using the information in this section. Microchip offers a unique programming service, where a few user-defined ocations in each device are programmed with different serial numbers. The serial numbers may be random, pseudo-random or sequential. Serial programming allows each device to have a unique number, which can serve as an entry code, password or ID number.

Parametrics

PIC16F505-I/SL absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: 0 to +6.5V; (4)Voltage on MCLR with respect to VSS: 0 to +13.5V; (5)Voltage on all other pins with respect to VSS: -0.3V to (VDD + 0.3V); (6)Total power dissipation: 800 mW; (7)Max. current out of VSS pin: 200 mA; (8)Max. current into VDD pin: 150 mA; (9)Input clamp current: ±20 mA; (10)Output clamp current: ±20 mA; (11)Max. output current sunk by any I/O pin: 25 mA; (12)Max. output current sourced by any I/O pin: 25 mA; (13)Max. output current sourced by I/O port: 75 mA; (14)Max. output current sunk by I/O port: 75 mA.

Features

PIC16F505-I/SL features: (1)High-Performance RISC CPU; (2)In-Circuit Debugging (ICD) support; (3)Power-on Reset (POR); (4)Device Reset Timer (DRT); (5)Watchdog Timer (WDT) with dedicated on-chip RC oscillator for reliable operation; (6)Programmable code protection; (7)8-bit real-time clock/counter (TMR0) with 8-bit programmable prescaler; (8)Fully static design; (9)Wide operating voltage range: 2.0V to 5.5V; (10)Low-power, high-speed Flash technology.
