Product Summary

PIC16F/LF1824/1828
14/20-Pin Flash Microcontrollers
with nanoWatt XLP Technology

Features

High-Performance RISC CPU:
? Only 49 Instructions to Learn:
- All single-cycle instructions except branches
? Operating Speed:
- DC – 32 MHz oscillator/clock input
- DC – 125 ns instruction cycle
? Up to 4 Kbytes Linear Program Memory
addressing
? Up to 256 bytes Linear Data Memory Addressing
? Interrupt Capability with Automatic Context
Saving
? 16-Level Deep Hardware Stack with Optional
Overflow/Underflow Reset
? Direct, Indirect and Relative Addressing modes:
- Two full 16-bit File Select Registers (FSRs)
- FSRs can read program and data memory
Flexible Oscillator Structure:
? Precision 32 MHz Internal Oscillator Block:
- Factory calibrated to ± 1%, typical
- Software selectable frequencies range of
31 kHz to 32 MHz
? 31 kHz Low-Power Internal Oscillator
? Four Crystal modes up to 32 MHz
? Three External Clock modes up to 32 MHz
? 4X Phase Lock Loop (PLL)
? Fail-Safe Clock Monitor:
- Allows for safe shutdown if peripheral clock
stops
? Two-Speed Oscillator Start-up
? Reference Clock module:
- Programmable clock output frequency and
duty-cycle
Special Microcontroller Features:
? 1.8V-5.5V operation – PIC16F1824/1828
? 1.8V-3.6V operation – PIC16LF1824/1828
? Self-Programmable under Software Control
? Power-on Reset (POR), Power-up Timer (PWRT)
and Oscillator Start-up Timer (OST)
? Programmable Brown-out Reset (BOR)
? Extended Watchdog Timer (WDT)
? In-Circuit Serial Programming? (ICSP?) via
two pins
? In-Circuit Debug (ICD) via Two Pins
? Enhanced Low-Voltage Programming (LVP)
? Operating Voltage Range:
- 1.8V-5.5V (PIC16F1824/1828)
- 1.8V-3.6V (PIC16LF1824/1828)
? Programmable Code Protection
? Power-Saving Sleep Mode
Extreme Low-Power Management
PIC16LF1824/1828 with nanoWatt XLP:
? Sleep mode: 20 nA
? Watchdog Timer: 500 nA
? Timer1 Oscillator: 600 nA @ 32 kHz
Analog Features:
? Analog-to-Digital Converter (ADC) module:
- 10-bit resolution, up to 12 channels
- Auto acquisition capability
- Conversion available during Sleep
? Analog Comparator module:
- Two rail-to-rail analog comparators
- Power mode control
- Software controllable hysteresis
? Voltage Reference module:
- Fixed Voltage Reference (FVR) with 1.024V,
2.048V and 4.096V output levels
- 5-bit rail-to-rail resistive DAC with positive
and negative reference selection
Peripheral Highlights:
? Up to 17 I/O Pins and 1 Input Only Pin:
- High current sink/source 25 mA/25 mA
- Programmable weak pull-ups
- Programmable interrupt-on-change pins
? Timer0: 8-Bit Timer/Counter with 8-Bit Prescaler
? Enhanced Timer1:
- 16-bit timer/counter with prescaler
- External Gate Input mode
- Dedicated, low-power 32 kHz oscillator driver
? Three Timer2-types: 8-Bit Timer/Counter with 8-Bit
Period Register, Prescaler and Postscaler
? Two Capture, Compare, PWM (CCP) modules
? Two Enhanced CCP (ECCP) modules:
- Software selectable time bases
- Auto-shutdown and auto-restart
- PWM steering
? Master Synchronous Serial Port (MSSP) with SPI
and I
2
CTM
with:
- 7-bit address masking
- SMBus/PMBus
TM
compatibility
? Enhanced Universal Synchronous Asynchronous
Receiver Transmitter (EUSART) module
? mTouch? Sensing Oscillator module:
- Up to 12 input channels
? Data Signal Modulator module:
- Selectable modulator and carrier sources
