Product Summary
PIC16F/LF1824/1828
14/20-Pin Flash Microcontrollers
with nanoWatt XLP Technology
Features
High-Performance RISC CPU:
? Only 49 Instructions to Learn:
- All single-cycle instructions except branches
? Operating Speed:
- DC – 32 MHz oscillator/clock input
- DC – 125 ns instruction cycle
? Up to 4 Kbytes Linear Program Memory
addressing
? Up to 256 bytes Linear Data Memory Addressing
? Interrupt Capability with Automatic Context
Saving
? 16-Level Deep Hardware Stack with Optional
Overflow/Underflow Reset
? Direct, Indirect and Relative Addressing modes:
- Two full 16-bit File Select Registers (FSRs)
- FSRs can read program and data memory
Flexible Oscillator Structure:
? Precision 32 MHz Internal Oscillator Block:
- Factory calibrated to ± 1%, typical
- Software selectable frequencies range of
31 kHz to 32 MHz
? 31 kHz Low-Power Internal Oscillator
? Four Crystal modes up to 32 MHz
? Three External Clock modes up to 32 MHz
? 4X Phase Lock Loop (PLL)
? Fail-Safe Clock Monitor:
- Allows for safe shutdown if peripheral clock
stops
? Two-Speed Oscillator Start-up
? Reference Clock module:
- Programmable clock output frequency and
duty-cycle
Special Microcontroller Features:
? 1.8V-5.5V operation – PIC16F1824/1828
? 1.8V-3.6V operation – PIC16LF1824/1828
? Self-Programmable under Software Control
? Power-on Reset (POR), Power-up Timer (PWRT)
and Oscillator Start-up Timer (OST)
? Programmable Brown-out Reset (BOR)
? Extended Watchdog Timer (WDT)
? In-Circuit Serial Programming? (ICSP?) via
two pins
? In-Circuit Debug (ICD) via Two Pins
? Enhanced Low-Voltage Programming (LVP)
? Operating Voltage Range:
- 1.8V-5.5V (PIC16F1824/1828)
- 1.8V-3.6V (PIC16LF1824/1828)
? Programmable Code Protection
? Power-Saving Sleep Mode
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PIC16F1824-I/SL |
Microchip Technology |
8-bit Microcontrollers (MCU) 7 KB Flash 256b RAM 32 MHz Int. Osc |
Data Sheet |
|
|
|||||||||||||
