Product Summary

PIC12F675T-I/SN is a Flash-Based 8-Bit CMOS Microcontroller. The PIC12F675T-I/SN has a 13-bit program counter capable of addressing an 8K x 14 program memory space. Only the first 1K x 14 (0000h-03FFh) for the PIC12F675T-I/SN is physically implemented. Accessing a location above these boundaries will cause a wrap-around within the first 1K x 14 space. The Reset vector is at 0000h and the interrupt vector is at 0004h .

Parametrics

PIC12F675T-I/SN absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: -0.3 to +6.5V; (4)Voltage on MCLR with respect to Vss: -0.3 to +13.5V; (5)Voltage on all other pins with respect to VSS: -0.3V to (VDD + 0.3V); (6)Total power dissipation: 800 mW; (7)Maximum current out of VSS pin: 300 mA; (8)Maximum current into VDD pin: 250 mA; (9)Input clamp current: 20 mA; (10)Output clamp current: 20 mA; (11)Maximum output current sunk by any I/O pin: 25 mA; (12)Maximum output current sourced by any I/O pin: 25 mA; (13)Maximum current sunk by all GPIO: 125 mA; (14)Maximum current sourced all GPIO: 125 mA.

Features

PIC12F675T-I/SN features: (1)High-Performance RISC CPU; (2)Internal and External Oscillator Options; (3)Power-Saving Sleep mode; (4)Wide Operating Voltage Range: 2.0V to 5.5V; (5)Industrial and Extended Temperature Range; (6)Low-Power Power-on Reset (POR); (7)Power-up Timer (PWRT) and Oscillator Start-up Timer (OST); (8)Brown-out Detect (BOD); (9)High Endurance Flash/EEPROM Cell; (10)High Current Sink/Source for Direct LED Drive; (11)Analog-to-Digital Converter module; (12)Low-Power Features.
