PCA9517DGKR

PCA9517DGKR, CMOS integrated circuit, 7 V, 50 mA, 100 mW, MSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: PCA9517DGKR

Brand:: Texas Instruments - TI | Pack: MSOP | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-01

From Other Seller

Part Number:PCA9517DGKR
US $1.00 - 3.00
Quantity:

piece

Product Summary

The PCA9517DGKR is a CMOS integrated circuit that provides level shifting between low voltage (down to 0.9 V) and higher voltage (2.7 V to 5.5 V) I2C or SMBus applications. While retaining all the operating modes and features of the I2C system during the level shifts, it also permits extension of the I2C-bus by providing bi-directional buffering for both the data (SDA) and the clock (SCL) lines, thus enabling two buses of 400 pF. Using the PCA9517DGKR enables the system designer to isolate two halves of a bus for both voltage and capacitance. The SDA and SCL pins are over voltage tolerant and are high-impedance when the PCA9517DP,118 is unpowered.

Parametrics

PCA9517DGKR absolute maximum ratings: (1)2.7 V to 3.3 V bus supply voltage range, VCCB: -0.5 to +7 V; (2)Adjustable bus supply voltage range, VCCA: -0.5 to +7 V; (3)Voltage range I2C-bus, SCL or SDA or enable (EN), Vbus: -0.5 to +7 V; (4)DC current (any pin), I: 50 mA; (5)Power dissipation, Ptot: 100 mW; (6)Storage temperature range, Tstg: -55 to +125℃; (7)Operating ambient temperature range, Tamb: -40 to +85℃; (8)Junction temperature, Tj: +125℃.
