OPA336NA/3K

CMOS operational amplifier, 7.5V, 10mA, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: OPA336NA/3K

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:OPA336NA/3K
US $0.30 - 0.50
Quantity:

piece

Product Summary

The OPA336NA/3K is a microPower CMOS operational amplifier which is designed for battery-powered applications. It operates on a single supply with operation as low as 2.1V. The output is rail-to-rail and swings to within 3mV of the supplies with a 100kΩ load. The common-mode range extends to the negative supply—ideal for single-supply applications. Single, dual, and quad versions have identical specifications for maximum design flexibility. Applications include battery-powered instruments, portable devices, high-impedance applications, photodiode pre-amps, precision integrators, medical instruments and test equipment.

Parametrics

OPA336NA/3K absolute maximum ratings: (1)Supply Voltage: 7.5V; (2)Signal Input Terminals-Voltage: (V-)-0.3V to (V+) +0.3V; (3)Signal Input Terminals-Current: 10mA; (4)Output Short-Circuit: Continuous; (5)Operating Temperature: -55℃ to +125℃; (6)Storage Temperature: -55℃ to +125℃; (7)Junction Temperature: 150℃; (8)Lead Temperature (soldering, 10s): 300℃.

Features

OPA336NA/3K features: (1)single-supply operation; (2)rail-to-rail output (within 3mV); (3)micropower: IQ = 20μA/amplifier; (4)microsize packages; (5)low offset voltage: 125μV max; (6)specified from vs = 2.3v to 5.5v; (7)single, dual, and quad versions.
