Product Summary

The MP1582EN is a monolithic step down switch mode converter with a built ininternal Power MOSFET. The MP1582EN achieves 2A continuous output current over a wide input supply range with excellent loadand line regulation. Current mode operation provides fast transient response and eases loop stabilization. Fault condition protection includes cycle-by-cycle current limiting and thermal shutdown.

Parametrics

MP1582EN absolute maximum ratings: (1)Supply Voltage (VVIN): 28V; (2)Switch Voltage (VSW): -1V to VIN +1V; (3)Boost Voltage VSW+ 6V; (4)Feedback Voltage (VFB): -0.3 to 6V; (5)EN/UVLO Voltage (VEN): -0.3 to 6V; (6)COMP Voltage (VCOMP): -0.3 to 6V; (7)Sync Voltage (VSync): -0.3 to 6V.

Features

MP1582EN features: (1)converter; (2)28V rated voltage; (3)2A rated current.

Diagrams

MP1582EN block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MP1582EN-LF
MP1582EN-LF
Monolithic Power Systems (MPS)
Switching Converters, Regulators & Controllers 2A 1.5MHz 28V Nonsync Buck
Data Sheet
0-1: $1.13
1-25: $1.06
25-100: $0.98
100-500: $0.90
MP1582EN-LF-Z
MP1582EN-LF-Z
Monolithic Power Systems (MPS)
Switching Converters, Regulators & Controllers 2A 1.5MHz 28V Nonsync Buck
Data Sheet
0-1760: $0.81
1760-2000: $0.78
2000-2500: $0.78
2500-5000: $0.76
