Product Summary

The MP1518DJ is a Fixed Frequency White LED Driver designed for backlights using white LEDs. The MP1518DJ is a 6 pin thin SOT23 step up converter designed for driving up to 6 series white LEDs from a single cell Lithium Ion battery. The MP1518DJ uses current mode, fixed frequency architecture to regulate the LED current, which is measured through an external current sense resistor. The applications of the MP1518DJ include Cell Phones, Handheld Computers and PDAs, Digital Still and Video Cameras, Small LCD Displays.

Parametrics

MP1518DJ absolute maximum ratings: (1)SW: -0.5V to 28V; (2)All Other Pins except: OV -0.3V to 6.5V.

Features

MP1518DJ features: (1)On Board Power MOSFET; (2)Drives up to 6 Series White LEDs; (3)Up to 86% Efficiency; (4)Over 1MHz Fixed Switching Frequency; (5)Open Load Shutdown; (6)Low 100mV Feedback Voltage; (7)Soft Start/PWM Dimming; (8)UVLO, Thermal Shutdown; (9)Internal Current Limit.

Diagrams

MP1518DJ block diagram
