MP1410ES

MP1410ES, monolithic step-down switch mode regulator, SOIC, -0.3V to +20V, 2A, Monolithic Power Systems

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: MP1410ES

Brand:: Monolithic Power Systems - MPS | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-25

From Other Seller

Part Number:MP1410ES
US $1.00 - 3.00
Quantity:

piece

Product Summary

The MP1410ES is a monolithic step-down switch mode regulator with a built in internal power MOSFET. It achieves 2A continuous output current over a wide input supply range with excellent load and line regulation. Current mode operation of MP1410ES provides fast transient response and eases loop stabilization. Fault condition protection includes cycle-by-cycle current limiting and thermal shutdown. In shutdown mode the regulator draws 25μA of supply current. The MP1410ES requires a minimum number of readily available standard external components. The applications of the MP1410ES include PC Monitors, Distributed Power Systems, Battery Charger, Pre-Regulator for Linear Regulators.

Parametrics

MP1410ES absolute maximum ratings: (1)Input Voltage (VIN): -0.3V to +20V; (2)Switch Voltage (VSW): -1V to VIN + 1V; (3)Boot Strap Voltage (VBS): VSW -0.3V to VSW + 6V; (4)All Other Pins: -0.3 to +6V; (5)Junction Temperature: 150℃; (6)Lead Temperature: 260℃; (7)Storage Temperature: -65℃ to +150℃.

Features

MP1410ES features: (1)2A Output Current; (2)0.22Ω Internal Power MOSFET Switch; (3)Stable with Low ESR Output Ceramic Capacitors; (4)Up to 95% Efficiency; (5)25μA Shutdown Mode; (6)Fixed 380KHz Frequency; (7)Thermal Shutdown; (8)Cycle-by-Cycle Over Current Protection; (9)Wide 4.75V to 20V Operating Input Range; (10)Output Adjustable from 1.22V to 13V; (11)Programmable Under Voltage Lockout; (12)Available in 8-Pin SOIC and PDIP Packages.
