MCP6042-I/P

MCP6042-I/P, Rail-to-Rail Input/Output Op Amp, 600 nA, 7.0 V, 14 kHz, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.35~0.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.40 / Piece
1001 ~ 10000 :	0.38 / Piece
10001 ~ 100000 :	0.35 / Piece

PartNumber:: MCP6042-I/P

Brand:: Microchip Technology - Microchip | Pack: DIP | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-04

From Other Seller

Part Number:MCP6042-I/P
US $0.35 - 0.40
Quantity:

piece

Product Summary

The MCP6042-I/P is a 600 nA, Rail-to-Rail Input/Output Op Amp. The MCP6042-I/P family of operational amplifiers from Microchip Technology, Inc. operate with a single supply voltage as low as 1.4 V, while drawing less than 1 μA (max) of quiescent current per amplifier. The MCP6042-I/P is also designed to support rail-to-rail input and output operation. This combination of features supports battery-powered and portable applications. Applications are (1)Toll Booth Tags; (2)Wearable Products; (3)Temperature Measurement; (4)Battery Powered.

Parametrics

MCP6042-I/P absolute maximum ratings: (1)VDD - VSS: 7.0 V; (2)All inputs and outputs: VSS –0.3 V to VDD +0.3 V; (3)Difference Input voltage: |VDD - VSS|; (4)Output Short Circuit Current: continuous; (5)Current at Input Pins: ±2 mA; (6)Current at Output and Supply Pins: ±30 mA; (7)Storage temperature: -65°C to +150°C; (8)Ambient temp. with power applied: -55°C to +125°C; (9)ESD protection on all pins (HBM): ≥ 4 kV.

Features

MCP6042-I/P features: (1)Low Quiescent Current: 600 nA/Amplifier (typ); (2)Rail-to-Rail Input: -0.3 V to VDD+0.3 V (max); (3)Rail-to-Rail Output: VSS+10 mV to VDD-10 mV (max); (4)Gain Bandwidth Product: 14 kHz (typ); (5)Wide Supply Voltage Range: 1.4 V to 5.5 V (max); (6)Unity Gain Stable; (7)Available in Single, Dual and Quad; (8)Chip Select (CS)with MCP6043; (9)5-lead SOT-23 package (MCP6041 only).
