Product Summary

The MBI6801 is a universal input AC-DC converter designed to deliver constant current to high power LED with primary side regulation (PSR) control (patent pending). The MBI6801 is optimized for applications based on flyback transformer-isolated converter with output power up to 10 Watts. The applications of the MBI6904 include LED Lamps, LED Sign and Channel Letter, Indication Sign, Low Power LEDs Lighting, < 1.5W.

Parametrics

MBI6801 absolute maximum ratings: (1)AC Input Voltage: 400V, transient; (2)Power Dissipation: 1.5 W; (3)Junction Temperature: 120℃.

Features

MBI6801 features: (1)Directly powered by 110 VAC; (2)Constant output current and Transformerless, 18 mA; (3)Drive one chain of LEDs, VOUT up to 60 V while applying 110V AC; (4)Reliable technology; (5)Small footprint 24-pin SOP24 package.

Diagrams

MBI6801 block diagram
