Product Summary

The MBI6024 is a 3x4-channel, constant-current, PWM-embedded sink driver for LED strips. The MBI6024 provides constant current ranging from 3mA to 45mA for each output channel and are adjustable with three corresponding external resistors. The appliations of the MBI6024 include LED strips, Mesh display, and Architcetural lighting.



Features

(1)3x4-channel constant-current sink driver for LED strips; (2)Constant current range: 3~45mA; (3)3 groups of output current, each group is set by an external resistor; (4)Sustaining voltage at output channels: 17V (max.); (5)Supply voltage 3V~5.5V; (6)Embedded 16-bit PWM generator; (7)Reliable data transmission; (8)Flexible PWM reset modes; (9)RoHS-compliant packages.
