MAX485ESA+T

MAX485ESA+T, low-power transceiver, SOP, 12V, 727mW, Maxim Integrated Products

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: MAX485ESA+T

Brand:: Maxim Integrated Products - Maxim | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-17

From Other Seller

Part Number:MAX485ESA+T
US $0.30 - 0.50
Quantity:

piece

Product Summary

The MAX485ESA+T is a low-power transceiver. It is designed as one kind of ±15kV ESD-protected, slew-rate-limited, low-power, RS-485/RS-422 transceiver device that can be used in wide range of applications such as low-power RS-485 transceivers, low-power RS-422 transceivers, Level translators, transceivers for EMI-sensitive applications, industrial-control local area networks. Also the MAX485ESA+T features reduced slewrate drivers that minimize EMI and reduce reflections caused by improperly terminated cables.

Parametrics

MAX485ESA+T absolute maximum ratings: (1)Supply Voltage (VCC): 12V; (2)Control Input Voltage (RE, DE): -0.5V to (VCC + 0.5V); (3)Driver Input Voltage (DI): -0.5V to (VCC + 0.5V); (4)Driver Output Voltage (A, B): -8V to +12.5V; (5)Receiver Input Voltage (A, B): -8V to +12.5V; (6)Receiver Output Voltage (RO): -0.5V to (VCC +0.5V); (7)Continuous Power Dissipation (TA = +70℃); (8)8-Pin Plastic DIP (derate 9.09mW/℃ above +70℃): 727mW; (9)14-Pin Plastic DIP (derate 10.00mW/℃ above +70℃): 800mW; (10)8-Pin SO (derate 5.88mW/℃ above +70℃): 471mW.

Features

MAX485ESA+T features: (1)For Fault-Tolerant Applications; (2)For Space-Constrained Applications; (3)For Multiple Transceiver Applications; (4)For Fail-Safe Applications; (5)For Low-Voltage Applications.
