MAX2659ELT+T

MAX2659ELT+T, GPS/GNSS Low-Noise Amplifier, QFN, -0.3V to +4.2V, 167mW, Maxim Integrated Products

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.30 / Piece
1001 ~ 10000 :	0.25 / Piece
10001 ~ 100000 :	0.20 / Piece

PartNumber:: MAX2659ELT+T

Brand:: Maxim Integrated Products - Maxim | Pack: DFN | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-26

From Other Seller

Part Number:MAX2659ELT+T
US $0.20 - 0.30
Quantity:

piece

Product Summary

The MAX2659ELT+T is a high-gain, low-noise amplifier (LNA) designed for GPS, Galileo, and GLONASS applications. Designed in Maxim’s advanced SiGe process, the device achieves a 20.5dB gain and an ultra-low-noise figure of 0.8dB while maximizing the input-referred 1dB compression point and the 3rd-order intercept point at -12dBm and -5dBm, respectively. The applications of the MAX2659ELT+T include Automotive Navigation, Location-Enabled Mobile Devices, Telematics (Asset Tracking and Management), Personal Navigation Device (PND), Cellular Phones with GPS, Notebook PC/Ultra-Mobile PC, Recreational, Marine Navigation, Avionics.

Parametrics

MAX2659ELT+T absolute maximum ratings: (1)VCC to GND: -0.3V to +4.2V; (2)Other Pins to GND: -0.3V to + Operating VCC + 0.3V; (3)Maximum RF Input Power: +10dBm; (4)Continuous Power Dissipation (TA = +70℃); (5)6-Pin μDFN (derates 2.1mW/℃ above +70℃): 167mW; (6)Operating Temperature Range: -40℃ to +85℃; (7)Junction Temperature: +150℃; (8)Storage Temperature Range: -65℃ to +160℃; (9)Lead Temperature (soldering, 10s): +260℃.

Features

MAX2659ELT+T features: (1)High-Power Gain: 20.5dB; (2)Ultra-Low-Noise Figure: 0.8dB; (3)Integrated 50Ω Output Matching Circuit; (4)Low Supply Current: 4.1mA; (5)Wide Supply Voltage Range: 1.6V to 3.3V; (6)Low Bill of Materials; (7)Small Footprint: 1.5mm x 1.0mm; (8)Thin Profile: 0.75mm; (9)Lead-Free and RoHS-Compliant Package.
