M27V322-100F1

32 Mbit EPROM, DIP, –2 to 7 V, 30mA, STMicroelectronics, M27V322-100F1

Rated 5 Rating 5 | reviews | Write a review

Price:: US $10.00~15.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	15.00 / Piece
11 ~ 100 :	12.00 / Piece
101 ~ 1000 :	10.00 / Piece

PartNumber:: M27V322-100F1

Brand:: STMicroelectronics - ST | Pack: DIP | D/C: 13+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-31

From Other Seller

Part Number:M27V322-100F1
US $10.00 - 15.00
Quantity:

piece

Product Summary

The M27V322-100F1 is a 32 Mbit EPROM offered in the UV range (ultra violet erase) and OTP range. It is ideally suited for microprocessor systems requiring large data or program storage. It is organised as 2 MWords of 16 bit. The pin-out is compatible a 32 Mbit Mask ROM. The M27V322-100F1 (window ceramic frit-seal package) has a transparent lid which allows the user to expose the chip to ultraviolet light to erase the bit pattern. A new pattern can then be written rapidly to the device by following the programming procedure. For applications where the content is programmed only one time and erasure is not required, the M27V322-100F1 is offered in PDIP42 package.

Parametrics

M27V322-100F1 absolute maximum ratings: (1)TA, Ambient Operating Temperature: –40 to 125 °C; (2)TBIAS, Temperature Under Bias: –50 to 125 °C; (3)TSTG, Storage Temperature: –65 to 150 °C; (4)VIO, Input or Output Voltage (except A9): –2 to 7 V; (5)VCC, Supply Voltage: –2 to 7 V; (6)VA9, A9 Voltage: –2 to 13.5V; (7)VPP, Program Supply Voltage: –2 to 14V.

Features

M27V322-100F1 features: (1)3.3V ± 10% supply voltage in read operation; (2)read access time–100ns at VCC = 3.0V to 3.6V; (3)pin compatible with M27C322; (4)word-wide configurable; (5)32 Mbit mask rom replacement; (6)low power consumption–Active Current 30mA at 5MHz; –Stand-by Current 60μA; (7)programming voltage: 12V ± 0.25V; (8)programming time: 50μs/word; (9)electronic signature: –Manufacturer Code: 0020h; –Device Code: 0034h.
