Product Summary
The LT 5521 is a very high linearity mixer optimized for
low distortion and low LO leakage applications. The chip
includes a high speed LO buffer with single-ended input
and a double-balanced active mixer. The LT5521 requires
only –5dBm LO input power to achieve excellent distortion and noise performance, while reducing external drive
circuit requirements. The LO buffer is internally 50?
matched for wideband operation.
With a 250MHz input, a 1.7GHz LO and a 1.95GHz output
frequency, the mixer has a typical IIP3 of +24.2dBm,
–0.5dB conversion gain and a 12.5dB noise figure.
The LT5521 offers exceptional LO-RF isolation, greatly
reducing the need for output filtering to meet LO suppression requirements.
The device is designed to work over a supply voltage range
from 3.15V to 5.25V.
Features
Wideband Output Frequency Range to 3.7GHz
■ +24.2dBm IIP3 at 1.95GHz RF Output
■ Low LO Leakage: –42dBm
■ Integrated LO Buffer: Low LO Drive Level
■ Single-Ended LO Drive
■ Wide Single Supply Range: 3.15V to 5.25V
■ Double-Balanced Active Mixer
■ Shutdown Function
■ 16-Lead (4mm ×4mm) QFN Package
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT5521EUF |
|
IC MIXER HI LIN 3.7GHZ 16-QFN |
Data Sheet |
|
|
||||||||||
|
LT5521EUF#PBF |
|
IC MIXER HI LIN 3.7GHZ 16-QFN |
Data Sheet |
|
|
||||||||||
|
LT5521EUF#TR |
|
IC MIXER HI LIN 3.7GHZ 16-QFN |
Data Sheet |
|
|
||||||||||
|
LT5521EUF#TRPBF |
|
IC MIXER HI LIN 3.7GHZ 16-QFN |
Data Sheet |
|
|
||||||||||
