LP2951CMMX

LP2951CMMX, micropower voltage regulator, 40 mV, 100 mA, 75 μA, 30 V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: LP2951CMMX

Brand:: Texas Instruments - TI | Pack: MSOP | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:LP2951CMMX
US $0.30 - 0.50
Quantity:

piece

Product Summary

The LP2951CMMX is a micropower voltage regulator with very low quiescent current (75μA typ.) and very low dropout voltage (typ. 40mV at light loads and 380mV at 100mA). The LP2951CMMX is ideally suited for use in battery-powered system. Furthermore, the quiescent current of the LP2951CMMX increases only slightly in dropout, prolonging battery life.

Parametrics

LP2951CMMX absolute maximum ratings: (1)Input Supply Voltage: -0.3 to +30V; (2)SHUTDOWN Input Voltage, Error Comparator Output Voltage, (Note 9)FEEDBACK Input Voltage (Note 9)(Note 10): -1.5 to +30V; (3)Power Dissipation: Internally Limited; (4)Junction Temperature (TJ): +150°C; (5)Ambient Storage Temperature: -65° to +150°C; (6)Soldering Dwell Time, Temperature Wave: 4 seconds, 260°C; (7)Soldering Dwell Time, Temperature Infrared: 10 seconds, 240°C; (8)Soldering Dwell Time, Temperature Vapor Phase: 75 seconds, 219°C; (9)ESD Rating Human Body Model(Note 18): 2500V; (10)Maximum Input Supply Voltage: 30V; (11)Junction Temperature Range (TJ)(Note 8)LP2951: -55°C to +150°C.

Features

LP2951CMMX features: (1)5V, 3V, and 3.3V versions available; (2)High accuracy output voltage; (3)Guaranteed 100mA output current; (4)Extremely low quiescent current; (5)Low dropout voltage; (6)Extremely tight load and line regulation; (7)Very low temperature coefficient; (8)Use as Regulator or Reference; (9)Needs minimum capacitance for stability; (10)Current and Thermal Limiting; (11)Stable with low-ESR output capacitors (10mΩ to 6Ω).
