LM56BIM, Dual Output Low Power Thermostat, SOIC, 12V, 5mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: LM56BIM

Brand:: Texas Instruments - TI | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:LM56BIM
US $0.30 - 0.50
Quantity:

piece

Product Summary

The LM56BIM is a Dual Output Low Power Thermostat. The LM56BIM is a precision low power thermostat. Two stable temperature trip points (VT1 and VT2) are generated by dividing down the LM56BIM 1.250V bandgap voltage reference using 3 external resistors. The LM56BIM has two digital outputs. OUT1 goes LOW when the temperature exceeds T1 and goes HIGH when the the temperature goes below (T1–THYST). Similarly, OUT2 goes LOW when the temperature exceeds T2 and goes HIGH when the temperature goes below (T2–THYST). THYST is an internally set 5℃ typical hysteresis. The LM56BIM is available in an 8-lead Mini-SO8 surface mount package and an 8-lead small outline package. The applications of the LM56BIM include Microprocessor Thermal Management, Appliances, Portable Battery Powered 3.0V or 5V Systems, Fan Control, Industrial Process Control, HVAC Systems, Remote Temperature Sensing, Electronic System Protection.

Parametrics

LM56BIM absolute maximum ratings: (1)Input Voltage: 12V; (2)Input Current at any pin (Note 2): 5 mA; (3)Package Input Current(Note 2): 20 mA; (4)Package Dissipation at TA = 25℃: 900 mW; (5)ESD Susceptibility (Note 4) Human Body Model: 1000V; (6)Machine Model: 200V; (7)Storage Temperature: -65℃ to +150℃.

Features

LM56BIM features: (1) Digital outputs support TTL logic levels; (2)Internal temperature sensor; (3)2 internal comparators with hysteresis; (4)Internal voltage reference; (5)Currently available in 8-pin SO plastic package; (6)Future availability in the 8-pin Mini-SO8 package.
