LM4991MA

audio power amplifier, 8SOIC, 2.2 V ~ 5.5 V, 1.5W, LM4991MA, National Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: LM4991MA

Brand:: Texas Instruments - TI | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:LM4991MA
US $0.30 - 0.50
Quantity:

piece

Product Summary

The LM4991MA is a mono bridged audio power amplifier capable of delivering 3W of continuous average power into a 3Ω load with less than 10% THD when powered by a 5V power supply. To conserve power in portable applications, the LM4991MA’s micropower shutdown mode (ISD =0.1μA, typ) is activated when VDD is applied to the SHUT-DOWN pin. The applications of the LM4991MA include Wireless and cellular handsets, PDA’s, Portable computers and Desktop computers.

Parametrics

LM4991MA absolute maximum ratings: (1)Supply Voltage: 6.0V; (2)Supply Temperature: -65℃ to +150℃; (3)Input Voltage: -0.3V to VDD to +0.3V; (4)Power Dissipation: Internally Limited; (5)ESD Susceptibility: 2000V; (6)ESD Susceptibility: 200V; (7)Junction Temperature: 150℃; (8)Thermal Resistance, θJC (LD): 4.3℃/W: θJA (LD): 56℃/W; θJC (MA): 35℃/W; θJA (MA): 140℃/W.

Features

LM4991MA features: (1)Available in space-saving LLP and MA packages; (2)Ultra low current shutdown mode; (3)Can drive capacitive loads up to 500pF; (4)Improved pop & click circuitry reduces noises during turn-on and turn-off transitions; (5)2.2 - 5.5V operation; (6)No output coupling capacitors, snubber networks, bootstrap capacitors or gain-setting resistors required; (7)Unity-gain stable.
