LM4910MAX

LM4910MAX, audio power amplifier, 6.0V, 6 mA, 35mW, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: LM4910MAX

Brand:: National Semiconductor - NS | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-31

From Other Seller

Part Number:LM4910MAX
US $0.30 - 0.50
Quantity:

piece

Product Summary

The LM4910MAX is an audio power amplifier primarily designed for headphone applications in portable device applications. It is capable of delivering 35mW of continuous average power to a 32Ω load with less than 1% distortion (THD+N) from a 3.3VDC power supply. The LM4910MAX utilizes a new circuit topology that eliminates output coupling capacitors and half-supply bypass capacitors (patent pending). The LM4910MAX contains advanced pop & click circuitry which eliminates noises caused by transients that would otherwise occur during turn-on and turn-off. Applications are (1)Mobile Phones; (2)PDAs; (3)Portable eletronics devices; (4)Portable MP3 players.

Parametrics

LM4910MAX absolute maximum ratings: (1)Supply Voltage: 6.0V; (2)Storage Temperature: -65°C to +150°C; (3)Input Voltage: -0.3V to VDD + 0.3V; (4)Power Dissipation: Internally Limited; (5)ESD Susceptibility Pin 6: 10kV; (6)ESD Susceptibility: 2000V; (7)ESD Susceptibility: 200V; (8)Junction Temperature: 150°C; (9)IDD Quiescent Power Supply Current VIN = 0V, 32Ω Load: 3.5 to 6 mA; (10)PO Output Power THD = 1% (max); f = 1kHz: 35mW.

Features

LM4910MAX features: (1)Eliminates headphone amplifier output coupling capacitors (patent pending); (2)Eliminates half-supply bypass capacitor (patent pending); (3)Advanced pop & click circuitry eliminates noises during turn-oand turn-off; (4)Ultra-low current shutdowmode; (5)Unity-gaistable; (6)2.2V - 5.5V operation; (7)Available ispace-saving MSOP, LLP, and SOIC packages.
