LM4051BIM3X-1.2

Precision Micropower Shunt Voltage Reference, 1.23V, SOT23-3, 20 mA, 280 mW, LM4051BIM3X-1.2

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: LM4051BIM3X-1.2

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:LM4051BIM3X-1.2
US $0.30 - 0.50
Quantity:

piece

Product Summary

The LM4051BIM3X-1.2 is a kind of Precision Micropower Shunt Voltage Reference. The LM4051BIM3X-1.2 advanced design eliminates the need for an external stabilizing capacitor while ensuring stability with any capacitive load, thus making the LM4051BIM3X-1.2 easy to use. Further reducing design effort is the availability of a fixed (1.225V) and adjustable reverse breakdown voltage. The LM4051BIM3X-1.2 is designed for: (1)Portable, Battery-Powered Equipment; (2)Data AcquisitioSystems; (3)Instrumentation; (4)Process Control; (5)Energy Management; (6)Automotive and Industrial; (7)PrecisioAudio Components; (8)Base Stations; (9)Battery Chargers; (10)Medical Equipment; (11)Communication.

Parametrics

LM4051BIM3X-1.2 absolute maximum ratings: (1)Reverse Current: 20 mA; (2)Forward Current: 10 mA; (3)Maximum Output Voltage (LM4051-ADJ): 15V; (4)Power Dissipation (TA = 25℃): M3 Package: 280 mW; (5)Storage Temperature: -65℃ to +150℃; (6)Lead Temperature: M3 Packages: Vapor phase (60 seconds): +215℃; Infrared (15 seconds): +220℃.

Features

LM4051BIM3X-1.2 features: (1)Small packages: SSOT-23; (2)No output capacitor required; (3)Tolerates capacitive loads; (4)Reverse breakdowvoltage options of 1.225V and adjustable.
