LM4040A25IDBZR

shunt voltage reference, 25 mA, 2.5V, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: LM4040A25IDBZR

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:LM4040A25IDBZR
US $0.30 - 0.50
Quantity:

piece

Product Summary

The LM4040A25IDBZR is a shunt voltage reference. It is a versatile, easy-to-use reference that caters to a vast array of applications. The 2-pin fixed-output device requires no external capacitors for operation and is stable with all capacitive loads. Additionally, the reference offers low dynamic impedance, low noise, and low temperature coefficient to ensure a stable output voltage over a wide range of operating currents and temperatures. The LM4040A25IDBZR uses fuse and Zener-zap reverse breakdown voltage trim during wafer sort to offer four output voltage tolerances, ranging from 0.1% (max) for the A grade to 1% (max) for the D grade. Thus, a great deal of flexibility is offered to designers in choosing the best cost-to-performance ratio for their applications. Applications include Data-Acquisition Systems, Power Supplies and Power-Supply, onitors, Instrumentation and Test Equipment, Process Controls, Precision Audio, Automotive Electronics, Energy Management and Battery-Powered Equipment.

Parametrics

LM4040A25IDBZR absolute maximum ratings: (1)Continuous cathode current: –10 to 25 mA; (2)Package thermal impedance-DBZ package: 206℃/W; (3)Package thermal impedance-DCK package: 252℃/W; (4)Package thermal impedance-LP package: 156℃/W; (5)Storage temperature range: -65 to 150℃; (6)Operating virtual junction temperature: 150℃.

Features

LM4040A25IDBZR features: (1)Fixed Output Voltages of 2.048 V, 2.5 V, 3 V, 4.096 V, 5 V, 8.192 V, and 10 V; (2)Tight Output Tolerances and Low Temperature Coefficient; (3)Low Output Noise; (4)Wide Operating Current Range; (5)Stable With All Capacitive Loads; No Output Capacitor Required; (6)Available in Extended Temperature Range.
