LM3423MH

LM3423MH, TSSOP, N-channel controller, -0.3V to 8.0V, -100μA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: LM3423MH

Brand:: National Semiconductor - NS | Pack: TSSOP | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-26

From Other Seller

Part Number:LM3423MH
US $0.30 - 0.50
Quantity:

piece

Product Summary

The LM3423MH is an N-channel controller for constant current led driver. The LM3423MH devices are versatile high voltage LED driver controllers. With the capability to be configured in a Buck, Boost, Buck-Boost (Flyback), or SEPIC topology, and an input operating voltage rating of 75V, these controllers are ideal for illuminating LEDs in a very diverse, large family of applications. The LM3423MH includes a high-voltage startup regulator that operates over a wide input range of 4.5V to 75V. The internal PWM controller is designed for adjustable switching frequencies of up to 2.0MHz, thus enabling compact solutions. The LM3423MH also includes an LED output status flag, a fault flag, a programmable fault timer, and a logic input to select the polarity of the dimming output driver. The LM3423MH can be applied in LED drivers, constant-current buck-boost regulator, constant-current boost regulator, constant-current flyback regulator, constant-current SEPIC regulator, and Thermo-Electric cooler (Peltier) drive.

Parametrics

LM3423MH absolute maximum ratings: (1)VIN,EN, PD, nDIM: -0.3V to 76.0V; (2)DPOL: -100μA continuous; (3)RCT: -0.3V to 76.0V; (4)VCC: -0.3V to 8.0V; (5)TIMR: -0.3V to 7.0V; (6)GATE, DDRV: -0.3V to VCC; (7)Maximum Junction Temperature (Internally Limited): 165°C; (8)torage Temperature Range -65°C to +150°C.
