LM2904DR

LM2904DR, Dual operational amplifier, SOIC, 3V, 0.7mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: LM2904DR

Brand:: Texas Instruments - TI | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-17

From Other Seller

Part Number:LM2904DR
US $0.30 - 0.50
LM2904DR

US $0.06 - 0.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM2904DR is a dual operational amplifier. Operation from split supplies also is possible if the difference between the two supplies is 3 V to 32 V (3 V to 26 V for the LM2904), and VCC is at least 1.5 V more positive than the input common-mode voltage. The low supply-current drain is independent of the magnitude of the supply voltage.

Parametrics

LM2904DR absolute maximum ratings: (1)Supply voltage: ±13 or 26 V; (2)Differential input voltage: ±26 V; (3)Input voltage: -0.3 to 26 V; (4)Duration of output short circuit (one amplifier) to ground at (or below) 25℃ free-air temperature (VCC ≤ 15 V): Unlimited; (5)Package thermal impedance: 85 ℃/W; (6)Operating free-air temperature range: -40 to 125 ℃; (7)Operating virtual junction temperature: -150 to 150 ℃; (8)Case temperature for 60 seconds FK package: 260 ℃; (9)Storage temperature range: -65 to 150 ℃.

Features

LM2904DR features: (1)Low Supply-Current Drain, Independent of Supply Voltage: 0.7 mA Typ; (2)Common-Mode Input Voltage Range Includes Ground, Allowing Direct Sensing Near Ground; (3)Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage: 26V; (4)Internal Frequency Compensation.
