FFA40UP20DNTU

FFA40UP20DNTU, ultrafast recovery power rectifier, 200 V, 20 A, 45ns, TO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: FFA40UP20DNTU

Brand:: Fairchild Semiconductor - Fairchild | Pack: TO | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-01

From Other Seller

Part Number:FFA40UP20DNTU
US $1.00 - 3.00
Quantity:

piece

Product Summary

The FFA40UP20DNTU is an ultrafast recovery power rectifier. Applications are (1)Output Rectifiers; (2)Switching Mode Power Supply; (3)Free-wheeling diode for motor application; (4)Power switching circuits.

Parametrics

FFA40UP20DNTU absolute maximum ratings: (1)VRRM Peak Repetitive Reverse Voltage: 200 V; (2)VRWM Working Peak Reverse Voltage: 200 V; (3)VR DC Blocking Voltage: 200 V; (4)IF(AV)Average Rectified Forward Current @ TC = 120°C: 20 A; (5)IFSM Non-repetitive Peak Surge Current 60Hz Single Half-Sine Wave: 200 A; (6)TJ, TSTG Operating Junction and Storage Temperature: - 65 to +150 °C.

Features

FFA40UP20DNTU features: (1)Ultrafast with Soft Recovery : < 45ns (@IF = 20A); (2)High Reverse Voltage : VRRM = 200V; (3)Avalanche Energy Rated; (4)Planar Construction.
