EPC1064PC8

EPC1064PC8, configuration device, 7.0 V, 250 mW, 50 mA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: EPC1064PC8

Brand:: Altera - Altera | Pack: DIP | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-02

From Other Seller

Part Number:EPC1064PC8
US $1.00 - 3.00
Quantity:

piece

Product Summary

The EPC1064PC8 control signals for configuration device—nCS, OE, and DCLK— interface directly with APEX II, APEX 20K, Mercury, ACEX 1K, and FLEX device control signals. The EPC1064PC8 can be configured by a configuration device without requiring an external intelligent controller. The EPC1064PC8 controls the tri-state buffer on the DATA output pin, and enable the address counter (and the oscillator in EPC4, EPC 8, EPC16, EPC2, EPC1, and EPC1441 devices). When OE is driven low, the configuration device resets the address counter and tristates its DATA pin.

Parametrics

EPC1064PC8 absolute maximum ratings: (1)VCC Supply voltage With respect to ground: –2.0 to 7.0 V; (2)VI DC input voltage With respect to ground: –2.0 to 7.0 V; (3)IMAX DC VCC or ground current: 50 mA; (4)IOUT DC output current, per pin: –25 to 25 mA; (5)PD Power dissipation: 250 mW; (6)TSTG Storage temperature No bias: –65 to 150 ° C; (7)TAMB Ambient temperature Under bias: –65 to 135 ° C; (8)TJ Junction temperature Under bias: 135 ° C.

Features

EPC1064PC8 features: (1)Serial device family for configuring APEXTM II, APEX 20K (including APEX 20K, APEX 20KC, and APEX 20KE), MercuryTM, ACEX 1K, and FLEX (FLEX 6000, FLEX 10KE, and FLEX 10KA)devices; (2)Easy-to-use 4-pin interface to APEX II, APEX 20K, Mercury, ACEX, and FLEX devices; (3)Low current during configuration and near-zero standby current; (4)5.0-V and 3.3-V operation; (5)Software design support with the Altera Quartus II and MAX+PLUS II development systems for Windows-based PCs as well as Sun SPARCstation, and HP 9000 Series 700/800; (6)Programming support with Alteras Master Programming Unit (MPU)and programming hardware from Data I/O, BP Microsystems, and other manufacturers; (7)Available in compact plastic packages; (8)EPC2 device has reprogrammable Flash configuration memory.
