Product Summary

The EP4CE6E22C8N is a high-performance, low-power FPGA.

Parametrics

EP4CE6E22C8N absolute maximum ratings: (1)supply voltage: 1.15 V to 1.25V; (2)Operating Temperature: 0℃ to 85℃.

Features

EP4CE6E22C8N features: (1)6K to 155K logic elements; (2)Up to 6 Mb of embedded memory; (3)Up to 360 18 × 18 multipliers for DSP processing intensive applications; (4)Protocol bridging applications for under 1.5W total power; (5)Data rates up to 3.125 Gbps; (6)8B10B encoder/decoder; (7)8-bit or 10-bit PMA to PCS interface; (8)Byte serializer/deserializer; (9)Word aligner; (10)Rate matching FIFO; (11)TX bit slipper for CPRI; (12)Electrical idle; (13)Dynamic channel reconfiguration allowing you to change data rates and protocols on-the-fly; (14)Static equalization and pre-emphasis for superior signal integrity; (15)150 mW per channel power consumption; (16)Flexible clocking structure to support multiple protocols in a single transceiver block; (17)×1, ×2, and ×4 lane configurations; (18)End point and root port configurations; (19)Up to 256-byte payload; (20)One virtual channel; (21)2 KB retry buffer; (22)4 KB RX buffer; (23)LVDS interfaces up to 840 Mbps TX, 875 Mbps RX; (24)Support for DDR2 SDRAM interfaces up to 200 MHz; (25)Support for QDRII SRAM and DDR SDRAM up to 167 MHz; (26)Up to eight PLLs per device; (27)Offered in commercial and industrial temperature grades.

Diagrams

EP4CE6E22C8N pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
EP4CE6E22C8N
EP4CE6E22C8N

IC CYCLONE IV FPGA 6K 144EQFP
Data Sheet
