ECG055B-G

ECG055B-G, InGaP HBT Gain Block, SOT, 50Ω, 150mA, TriQuint Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: ECG055B-G

Brand:: TriQuint Semiconductor - TriQuint | Pack: SOT | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:ECG055B-G
US $0.30 - 0.50
Quantity:

piece

Product Summary

The ECG055B-G is an InGaP HBT Gain Block. The ECG055B-G is a general-purpose buffer amplifier that offers high dynamic range in a low-cost surface-mount package. At 1000 MHz, the ECG055B-G typically provides 20 dB of gain, +34 dBm Output IP3, and +18 dBm P1dB. The ECG055B-G consists of Darlington pair amplifiers using the high reliability InGaP/GaAs HBT process technology and only requires DC-blocking capacitors, a bias resistor, and an inductive RF choke for operation. The device is ideal for wireless applications and is available in low-cost, surface-mountable plastic SOT-86 and SOT-89 packages. The ECG055B-G is also available in a leadfree/green/RoHS-compliant SOT-89 package. All devices are 100% RF and DC tested. The broadband MMIC amplifier can be directly applied to various current and next generation wireless technologies such as GPRS, GSM, CDMA, and WCDMA. In addition, the ECG055 will work for other various applications within the DC to 3 GHz frequency range such as CATV and fixed wireless. The applications of the ECG055B-G include Mobile Infrastructure, CATV / DBS, W-LAN / ISM, RFID, Defense / Homeland Security, Fixed Wireless.

Parametrics

ECG055B-G absolute maximum ratings: (1)Operating Case Temperature: -40 to +85 ℃; (2)Storage Temperature: -65 to +150 ℃; (3)RF Input Power (continuous): +12 dBm; (4)Device Current: 150 mA; (5)Junction Temperature: +250 ℃.

Features

ECG055B-G features: (1)DC – 3 GHz; (2)+18 dBm P1dB at 1 GHz; (3)+34 dBm OIP3 at 1 GHz; (4)20 dB Gain at 1 GHz; (5)4.3 dB Noise Figure at 2 GHz; (6)Available in SOT-86, SOT-89 89 and lead-free / green SOT-89 Package Styles; (7)Internally matched to 50 Ω.
