ECG015B-G

InGaP HBT Amplifier, High Linearity, +15 dBm, 180 mA, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: ECG015B-G

Brand:: TriQuint Semiconductor - TriQuint | Pack: SOT | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:ECG015B-G
US $0.30 - 0.50
Quantity:

piece

Product Summary

The ECG015B-G is a high dynamic range driver amplifier in a low-cost surface mount package. The InGaP/GaAs HBT is able to achieve performance over a broad range with +41 dBm OIP3 and +24 dBm of compressed 1dB power and is housed in a lead-free/green/RoHS-compliant SOT-89 SMT package. All devices are 100% RF and DC tested. The ECG015B-G is targeted for use as a gain block/driver amplifier for various current and next generation wireless technologies such as GPRS, UMTS and WCDMA, where high linearity and medium power is required. In addition, the ECG015B-G will work for numerous other applications within the 1800 to 2500 MHz frequency range. Applications include Mobile Infrastructure, W-LAN / ISM, RFID, Defense / Homeland Security and Fixed Wireless.

Parametrics

ECG015B-G absolute maximum ratings: (1)Operating Case Temperature: -40 to +85℃; (2)Storage Temperature: -55 to +125℃; (3)Device Current: 180 mA ; (4)RF Input Power (continuous): +15 dBm; (5)Junction Temperature: +250℃.

Features

ECG015B-G features: (1)1800-2500 MHz; (2)+24 dBm P1dB ; (3)+41 dBm OIP3; (4)15 dB Gain; (5)5 dB Noise Figure; (6)Single Positive Supply (+8V); (7)Available in a lead-free / green SOT-89 Package Style.
