Product Summary

The DS2780E+ is a Low-Voltage Dual SPST Analog Switch. The DS2780E+ is a dual single-pole/single-throw monolithic CMOS analog switch designed for high performance switching of analog signals. Combining low power, high speed (tON: 25 ns, tOFF: 20 ns), the DS2780E+ is ideal for portable and battery powered applications requiring high performance and efficient use of board space. The DS2780E+ is built on Vishay Siliconix’s low voltage BCD-15 process. The applications of the DS2780E+ include Battery Operated Systems, Portable Test Equipment, Sample and Hold Circuits, Cellular Phones, Communication Systems, Military Radio, PBX, PABX Guidance and Control Systems.

Parametrics

DS2780E+ absolute maximum ratings: (1)Reference to GND V+: -0.3 to +13.5 V; (2)IN, COM, NC, NOa: -0.3 to (V+ + 0.3 V); (3)Continuous Current (Any terminal): ±10 mA; (4)Peak Current: ±20 mA; (5)Storage Temperature (D Suffix): -65 to 150 ℃; (6)Power Dissipation (Packages): 320 mW.

Features

DS2780E+ features: (1)Wide Operation Voltage (+2.7 to +12 V); (2)Low Charge Injection - QINJ: 1 pC; (3)Low Power Consumption; (4)TTL/CMOS Logic Compatible Over The Full Operating Voltage range; (5)Available in MSOP-8 and SOT23-8.

Diagrams

DS2780E+ block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
DS2780E+
DS2780E+
Maxim Integrated Products
Battery Management Stand-Alone Fuel Gauge
Data Sheet
0-1: $4.57
1-25: $3.07
25-50: $2.23
50-100: $2.20
DS2780E+T&R
DS2780E+T&R
Maxim Integrated Products
Battery Management Stand-Alone Fuel Gauge
Data Sheet
0-2080: $1.85
2080-2500: $1.85
