DF6A6.8FUT1G

DF6A6.8FUT1G, quad voltage suppressor, 75 Watts, 16KV, 5 mA, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	5.00 / Piece
501 ~ 1000 :	3.50 / Piece
1001 ~ 3000 :	2.00 / Piece

PartNumber:: DF6A6.8FUT1G

Brand:: ON Semiconductor - ON | Pack: SOT | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-01

From Other Seller

Part Number:DF6A6.8FUT1G
US $2.00 - 5.00
Quantity:

piece

Product Summary

The DF6A6.8FUT1G quad voltage suppressor is designed for applications requiring transient overvoltage protection capability. The DF6A6.8FUT1G is intended for use in voltage and ESD sensitive equipment such as computers, printers, business machines, communication systems, medical equipment, and other applications. Its quad junction common anode design protects four separate lines using only one package. These devices are ideal for situations where board space is at a premium.

Parametrics

DF6A6.8FUT1G absolute maximum ratings: (1)Peak Power Dissipation @ 8 x 20 μs (Note 1)Ppk: 75 Watts; (2)Steady State Power Dissipation (Note 2)PD: 385 mW; (3)Maximum Junction Temperature TJmax: 150 °C; (4)Operating Junction and Storage Temperature Range TJ, Tstg: −55 to +150 °C; (5)ESD Discharge MIL STD 883C − Method 3015−6: 16KV, IEC61000−4−2, Air Discharge: 16KV, IEC61000−4−2, Contact Discharge: 8KV; (6)Lead Solder Temperature (10 seconds duration)TL: 260 °C.

Features

DF6A6.8FUT1G features: (1)SC−88 Package Allows Four Separate Unidirectional Configurations; (2)Low Leakage < 1 A @ 5 Volt; (3)Breakdown Voltage: 6.4 − 7.2 Volt @ 5 mA; (4)Low Capacitance (40 pF typical); (5)ESD Protection Meeting 61000−4−2 Level 4 and 16 kV Human Body Model; (6)Pb−Free Package is Available.
