CC2540F256RHAR

system-on-chip, cost-effective, 12-Bit, 2 kV, QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: CC2540F256RHAR

Brand:: Texas Instruments - TI | Pack: QFN | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:CC2540F256RHAR
US $0.30 - 0.50
Quantity:

piece

Product Summary

The CC2540F256RHAR is a cost-effective, low-power, true system-on-chip (SoC) for Bluetooth low energy applications. It enables robust BLE master or slave nodes to be built with very low total bill-of-material costs. The CC2540F256RHAR combines an excellent RF transceiver with an industry-standard enhanced 8051 MCU, in-system programmable flash memory, 8-KB RAM, and many other powerful supporting features and peripherals. The CC2540F256RHAR is suitable for systems where very low power consumption is required. Very low-power sleep modes are available. Short transition times between operating modes further enable low power consumption. Applications include 2.4-GHz Bluetooth low energy Systems, Mobile Phone Accessories, Sports and Leisure Equipment, Consumer Electronics, Human Interface Devices (Keyboard, Mouse,Remote Control), USB Dongles and Health Care and Medical.

Parametrics

CC2540F256RHAR absolute maximum ratings: (1)Supply voltage: -0.3 to 3.9 V; (2)Voltage on any digital pin: –0.3 to VDD + 0.3V; (3)Input RF level: 10 dBm; (4)Storage temperature range: -40 to 85℃.

Features

CC2540F256RHAR features: (1)6-mm×6-mm Package; (2)Few External Components; (3)Reference Design Provided; (4)12-Bit ADC with Eight Channels and Configurable Resolution; (5)Integrated High-Performance Op-Amp and Ultralow-Power Comparator; (6)General-Purpose Timers (One 16-Bit, Two 8-Bit); (7)Two Powerful USARTs With Support for Several Serial Protocols; (8)Royalty-Free Bluetooth low energy Protocol Stack.
