CC2531F256RHAR

CC2531F256RHAR, A USB Enabled System-On-Chip Solution, QFN, -0.3V, 3.9V, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: CC2531F256RHAR

Brand:: Texas Instruments - TI | Pack: QFN | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:CC2531F256RHAR
US $0.30 - 0.50
Quantity:

piece

Product Summary

The CC2531F256RHAR is a USB Enabled System-On-Chip Solution. The CC2531F256RHAR is a USB enabled true system-on-chip (SoC) solution for IEEE 802.15.4, Zigbee and RF4CE applications. It enables USB dongles or USB upgradable network nodes to be built with low total bill-of-material costs. The CC2531F256RHAR combines the performance of a leading RF transceiver with an industry-standard enhanced 8051 MCU, in-system programmable flash memory, 8-KB RAM, and many other powerful features. The CC2531F256RHAR has various operating modes, making it suited for systems where ultralow power consumption is required. Short transition times between operating modes further ensure low energy consumption. Source code for USB HID and CDC libraries and examples are downloadable from the CC2531F256RHAR product page on www.ti.com.

Parametrics

CC2531F256RHAR absolute maximum ratings: (1)Supply voltage : –0.3 to 3.9 V; (2)Voltage on any digital pin : –0.3 to VDD +≤0.3 V; (3)Input RF level : 10 dBm; (4)Storage temperature range : –40 to 125 ℃; (5)ESD : 500 V.

Features

CC2531F256RHAR features: (1)2.4-GHz IEEE 802.15.4 Compliant RF Transceiver ; (2)Excellent Receiver Sensitivity and Robustness to Interference; (3)Programmable Output Power Up to 4.5 dBm; (4)Few External Components; (5)Only a Single Crystal Needed for Mesh Network Systems; (6)6-mm × 6-mm QFN40 Package.
