CC1110F32RSPR

System-on-Chip, Sub-1 GHz, 3.6V, 10 dBm, QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: CC1110F32RSPR

Brand:: Texas Instruments - TI | Pack: QFN | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:CC1110F32RSPR
US $0.30 - 0.50
CC1110F32RSPR

US $1.00 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The CC1110F32RSPR is a true low-power sub-1 GHz system-on-chip (SoC) designed for lowpower wireless applications. The CC1110F32RSPR combines the excellent performance of the state-of-the-art RF transceiver with an industry-standard enhanced 8051 MCU, up to 32 kB of in-system programmable flash memory and up to 4 kB of RAM, and many other powerful features. The small 6x6 mm package makes it very suited for applications with size limitations. The CC1110F32RSPR is highly suited for systems where very low power consumption is required. This is ensured by several advanced low-power operating modes. The CC1110F32RSPR adds a full-speed USB 2.0 interface to the feature set of the CC1110F32RSPR. Interfacing to a PC using the USB interface is quick and easy, and the high data rate (12 Mbps) of the USB interface avoids the bottlenecks of RS-232 or low-speed USB interfaces. Applications include Wireless alarm and security systems, Industrial monitoring and control and Wireless sensor networks.

Parametrics

CC1110F32RSPR absolute maximum ratings: (1)Supply voltage (VDD): -0.3 to 3.9 V; (2)Voltage on any digital pin: -0.3 to VDD + 0.3,max 3.9 V ; (3)Voltage on the pins RF_P, RF_N and DCOUPL: -0.3 to 2.0 V ; (4)Voltage ramp-up rate: 120 kV/μs ; (5)Input RF level: 10 dBm; (6)Storage temperature range: -50 to 150℃; (7)Solder reflow temperature: 260℃.

Features

CC1110F32RSPR features: (1)Radio; (2)Low Power; (3)AMR-Automatic Meter Reading; (4)Home and building automation; (5)Low power telemetry ; (6)USB dongles; (7)MCU, Memory, and Peripherals; (8)Wide supply voltage range (2.0V - 3.6V) ; (9)RoHS compliant 6x6 mm QLP36 package.
