AT24C32D-MAHM-T

AT24C32D-MAHM-T, 2-Wire Serial Electrically Erasable, Programmable Read-only Memory, DFN, 5mA, 6.25V, ATMEL Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: AT24C32D-MAHM-T

Brand:: ATMEL Corporation - ATMEL | Pack: DFN | D/C:

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-17

From Other Seller

Part Number:AT24C32D-MAHM-T
US $0.30 - 0.50
Quantity:

piece

Product Summary

The AT24C32D-MAHM-T is a 2-Wire Serial Electrically Erasable and Programmable Read-only Memory. The AT24C32D-MAHM-T provides 32,768-/65,536-bits of serial electrically erasable and programmable read only memory (EEPROM) organized as 4096/8192 words of 8-bits each. The AT24C32D-MAHM-T is optimized for use in many industrial and commercial applications where low power and low voltage operation are essential. The AT24C32D-MAHM-T is available in space saving 8-lead JEDEC SOIC, 8-lead TSSOP, 8-lead UDFN, 8-lead XDFN, 5-lead SOT23 and 8-ball VFBGA and is accessed via a 2-wire serial interface. In addition, the entire family operates from 1.7V to 5.5V.

Parametrics

AT24C32D-MAHM-T absolute maximum ratings: (1)Operating Temperature: -55 to +125℃; (2)Storage Temperature: -65 to +150℃; (3)Voltage on Any Pin with Respect to Ground: -1.0 to +7.0V; (4)Maximum Operating Voltage: 6.25V; (5)DC Output Current: 5.0mA.

Features

AT24C32D-MAHM-T features: (1)Low-voltage and Standard-voltage Operation VCC = 1.7 to 5.5V; (2)Internally Organized 4096 x 8, 8192 x 8; (3)2-Wire Serial Interface; (4)Schmitt Trigger, Filtered Inputs for Noise Suppression; (5)Bi-directional Data Transfer Protocol; (6)1MHz (5.0V) and 400KHz (1.8V Compatibility); (7)Write Protect Pin for Hardware Data Protection; (8)32-Byte Page Write Mode (Partial Page Writes Allowed); (9)Self-Timed Write Cycle (5ms max); (10)High Reliability; (11)Endurance: 1 Million Write Cycles; (12)Data Retention: 100 Years; (13)Lead-free/Halogen-free Devices; (14)8-lead JEDEC SOIC, 8-lead TSSOP, 8-lead UDFN, 8-lead XDFN, 5-lead SOT23 and 8-ball VFBGA; (15)Die Sales: Wafer Form, Waffle Pack and Bumped Wafers.
